Incorporating air technology, the Ecohog Tracked Windshifter (EH-1500 TWS) facilitates fraction separation based on desired density.
Pictured is the Ecohog EH1500-TWS tracked Windshifter on skip waste with light fraction being removed. The process of this site was the Ecohog tracked Windshifter teamed with the Terex EcoTec TTS 620T Trommel tackling the separation of pre-screened Skip Waste concentrating on the 0-80mm oversize fraction.
0-22mm Fines Removal
0-20mm Fines Removal from Terex EcoTec TTS 620T Trommel initially screened the 0-80mm material to remove the 0-20mm fines element of the material. Removing the fines fraction enhances the overall production, increasing the separation process and adding value to the recovered material. The remaining 20-80mm oversize fraction passes from the TTS 620T Trommel into the Ecohog EH1500-TWS tracked Windshifter. 20-80mm Separation the Ecohog Tracked Windshifter operates on the principle of density differentiation and separates heavy material from the light material.
The Ecohog Windshifter’s unique technology in air concept and precision setting capabilities ensures the heavy fraction can be separated from the light fraction to accommodate the end users material requirements. The heavies’ fraction discharge conveyor on the EH1500-TWS Windshifter is also equipped with a magnetic head drum to recover ferrous metals from the heavy material, recuperating another profitable by-product.
The Result In this particular composite of material, the end products recovered included a 0-20mm fines fraction, 20-80mm clean aggregate, 20-80mm SRF light fraction and a saleable scrap steel fraction.
The Ecohog range has been designed to work in conjunction with various industry machines such as trommels and screens to enhance the quality of fraction separation. The Ecohog Windshifter is available in both static and mobile installations with optional auxiliaries depending on the application and customer requirements.
The Ecohog Windshifter range is capable of achieving up to 99% separation, depending on the application and is suitable for processing a variety of applications such as but not limited to;
- Compost / Compost Oversize
- Construction & Demolition waste (C&D)
- Construction & Industrial waste (C&I)
- Glass (MRF) Clean up
- Trommel Fines
- Waste Wood processing
- RDF / SRF
- Green Waste
